Description
Specifications:
| DCV | 0.1/2.5/10/50/250V ±3.0%FSD, 1000V ±4.0%FSD |
| ACV | 10/50/250V ±4.0%FSD, 1000V±5.0%FSD |
| DCA | 0.05/2.5/25/250 mA ±3.0%FSD |
| Resistance | ×1(0.2~2kΩ)/ ×10(2~20kΩ)/ ×100(20~200kΩ)/ ×1k(200~2MΩ)/ ×10kΩ(2k~20MΩ) ±4.0%ARC of scale length |
| Capacitance | C(RX1K):2000uF (Approx.)Max |
| Battery check | 1.5V/9V |
| Transistor hFE test | hFE: 0-1000 |
| Diode & LED test | Y |
| Continuity with beeper | Y |
| Front Panel Controls | Range selector switch with “OFF” position, 0Ω adjust knob |
| Power source | 1.5V AAA x2 & 9V(NEDA1604) x1 (Not Included) |
| Size | 160 x 105 x 40 mm |
| Individual packing | Color box |
