Description
The ProsKit MT-1236 is a compact True RMS digital multimeter that provides accurate electrical measurements for AC/DC voltage, current, resistance, capacitance, frequency and temperature. It’s autoranging design and multiple testing functions make it ideal for professionals and DIY users.
Features:
- 3½-digit LCD display (1999 counts)
- True RMS AC voltage and current measurement
- Measures AC/DC voltage and current
- Resistance and capacitance measurement
- Transistor (hFE) test
- Diode test
- Continuity test with beeper
- Auto power-off after 15 minutes
- Low battery indication
- Compact and lightweight design
- Suitable for electrical maintenance and electronics troubleshooting
Specifications:
| Model No. | MT-1226 |
| Display | 3 5/6 Digit LCD, Max. 5999 counts |
| Measurement | Auto range |
| Safety Rating | CAT II 600V |
| DC Voltage | 600mV / 6V / 60V / 600V ± (0.5% + 5d) |
| AC Voltage | 600mV / 6V / 60V / 600V ± (1% + 4d), True RMS |
| DC Current | 60mA / 600mA ± (1.2% + 5d), 10A ± (3.0% + 5d) |
| AC Current | 60mA / 600mA ± (1.5% + 5d), 10A ± (3.0% + 5d), True RMS |
| Resistance | 600Ω / 6kΩ / 60kΩ / 600kΩ / 6MΩ / 60MΩ ± (0.8% + 5d) |
| Frequency | 9.999Hz to 9.999MHz ± (1.5% + 5d) |
| Duty Cycle | 1%–99% ± (2.5% + 5d) |
| Capacitance | 60nF / 600nF / 6µF / 60µF / 600µF / 6mF / 100mF |
| Temperature | -20°C to 1000°C (-4°F to 1832°F) |
| Continuity Test | ≤30Ω with buzzer |
| Diode Test | Yes |
| LED Test | Yes |
| NCV Detection | Yes (AC 30V–600V, 50/60Hz) |
| Data Hold | Yes |
| Backlight | Yes |
| Low Battery Indicator | Yes |
| Battery | 3 × 1.5V AAA |
| Dimensions | 148 × 79 × 48 mm |
